KR260のBootmode設定メモ

KR260を動かそうとするたびにjtag boot modeに切り替える方法を忘れてXilinxのサイトを探すのが手間なので，ここにメモしておく．

VitisのXSCTから以下を実行

connect
source kr260_boot.tcl
boot_jtag

kr260_boot.tlcの内容は以下の通り

proc boot_jtag { } {
############################
# Switch to JTAG boot mode #
############################
targets -set -filter {name =~ "PSU"}
# update multiboot to ZERO
mwr 0xffca0010 0x0
# change boot mode to JTAG
mwr 0xff5e0200 0x0100
# reset
rst -system
}

出典

Setting Bootmodes — Kria™ SOM 2022.1 documentation
xilinx.github.io
